Technical Specifications


  • Operating Voltage: 20V-70V.
  • Power Consumption: 5W (Nominal).
  • Dimensions: 130mm x 145mm x 43mm (WxDxH).
  • Operating Temperature Range: -20°C to +60°C.

System Interfaces:

  • Supports small to large systems by connecting upto 60 rectifiers.
  • Dynamic battery current control and temperature compensation.
  • Upto 3 voltage, 2 current channels and 1 temperature channel.
  • Up to 2 LVD Controls – one each for battery and load.
  • Up to 8 potential free inputs / outputs using external unit.

Communication Interfaces:

  • 1 x isolated system CAN bus.
  • 1 x isolated RS485.
  • 10/100 Mbps Ethernet interface-MDI/MDI-X, Static/DHCP IP, IPv4, HTTP, SNMP V2c/V3, and SNTP.
  • USB 2.0b interface-supports mass storage. Host mode and device mode for programming.
  • Modbus RTU Interface for SCADA system.
